MAGNARO® Float rope
MAGNARO® Float is a mixed or composite rope of high tenacity polyolefin and high performance polyester. A special marine finish is applied to further increase the wear resistance in a marine environment.
The rope offers very good abrasion resistance and very high strength. Its buoyancy and excellent handling properties make it the ideal mooring rope for all types of ships.
product properties
Specifications
| Material | High tenacity polyolefin & high tenacity polyester |
|---|---|
| Construction | 8- or 12-strand |
| Jacketed | No |
| Rotating | No |
| Color of rope | White with 2 red markers |
| Specific gravity | 0.99 (floating) |
| Melting point | 165 °C / 260 °C |
| Abrasion resistance | Very good |
| U.V. resistance | Very good |
| Chemical resistance | Very good |
| Dry & wet conditions | Identical wet & dry strengths |
Sizes and breaking loads
| Dia. (mm) | Circ. (inch) | Weight (kg/100m) | MBL (unspliced) | MBL/LDBF* (spliced) | ||
|---|---|---|---|---|---|---|
| Ton | kN | Ton | kN | |||
| 28 | 3 1/2 | 44.7 | 16.8 | 165 | 15.1 | 149 |
| 30 | 3 3/4 | 51.4 | 19.4 | 190 | 17.4 | 171 |
| 32 | 4 | 58.5 | 22.0 | 216 | 19.8 | 194 |
| 34 | 4 1/4 | 66.0 | 24.8 | 243 | 22.3 | 218 |
| 36 | 4 1/2 | 72.0 | 28.0 | 275 | 25.2 | 247 |
| 38 | 4 3/4 | 80.2 | 31.2 | 305 | 28.0 | 274 |
| 40 | 5 | 83.6 | 36.7 | 360 | 33.0 | 324 |
| 42 | 5 1/4 | 92.1 | 40.5 | 397 | 36.4 | 356 |
| 44 | 5 1/2 | 99.1 | 44.0 | 431 | 39.6 | 388 |
| 46 | 5 3/4 | 108 | 48.1 | 471 | 43.2 | 423 |
| 48 | 6 | 118 | 50.5 | 495 | 45.4 | 446 |
| 50 | 6 1/4 | 128 | 54.9 | 538 | 49.3 | 483 |
| 52 | 6 1/2 | 136 | 58.8 | 576 | 52.9 | 518 |
| 54 | 6 3/4 | 147 | 63.4 | 622 | 57.0 | 558 |
| 56 | 7 | 158 | 67.7 | 663 | 60.9 | 598 |
| 58 | 7 1/4 | 169 | 72.7 | 712 | 65.3 | 640 |
| 60 | 7 1/2 | 179 | 77.5 | 760 | 69.7 | 684 |
| 62 | 7 3/4 | 191 | 82.8 | 812 | 74.4 | 729 |
| 64 | 8 | 203 | 87.0 | 853 | 78.3 | 768 |
| 66 | 8 1/4 | 216 | 92.6 | 907 | 83.2 | 815 |
| 68 | 8 1/2 | 228 | 98.1 | 961 | 88.2 | 865 |
| 70 | 8 3/4 | 242 | 104 | 1,020 | 93.5 | 916 |
| 72 | 9 | 255 | 109 | 1,068 | 98.1 | 961 |
| 76 | 9 1/2 | 284 | 122 | 1,192 | 109 | 1,071 |
| 80 | 10 | 313 | 132 | 1,294 | 119 | 1,165 |
| 84 | 10 1/2 | 345 | 146 | 1,428 | 131 | 1,283 |
| 88 | 11 | 376 | 157 | 1,539 | 141 | 1,385 |
| 92 | 11 1/2 | 411 | 172 | 1,684 | 154 | 1,514 |
| 96 | 12 | 447 | 191 | 1,872 | 172 | 1,685 |
* LDBF as per OCIMF MEG4 recommendations (spliced dry condition).
Elongation
| Break force | Elongation |
|---|---|
| 10% | 4.3% |
| 30% | 8.6% |
| 50% | 11.7% |
| 100% | 16.1% |
